The Horizontal Form Seal Machine is also named as Pillow Packing Machine. In the bagging and forming unit the heat sealable film such as PE/OPP, flowing horizontally flip and folds around a forming bag, then back center are imparted by vertical sealing units to seal the bag.
Model | KD-260 | KD-350 | KD-450 | KD-590 | KD-720 |
Max Film Width | 260mm | 350mm | 450mm | 590mm | 720mm |
Product Length | 40-330mm | 40-400mm | 40-450mm | 40-500mm | 40-600mm |
Product Width | 30-110mm | 40-160mm | 50-210mm | 60-280mm | 60-320mm |
Product Height | 50mm | 80mm | 80mm | 120mm | 150mm |
Intensity of Sealing | >15N/mm² | ||||
Packing Speed | 40-250 packages/minute | ||||
Packing Material | BOPP/PE, CPP/PE, CPP/PA, BOPP, CPP Anti-Fog Film, OPP Film, Color Film, and so on | ||||
Thickness of Film | 0.02-0.08mm | ||||
Power | 2.4KW 220V | 2.4KW 220V | 2.4KW 220V | 2.8KW 220V | 3.6KW 220V |
Overall Dimension | 4100x950x1500mm | 4100x1000x1500mm | 4100x1050x1500mm | 5100x1050x1700mm | 5100x1300x1700m |
Weight | 550KGS | 600KGS | 680KGS | 800KGS | 1000KGS |
The Horizontal Form Seal Machine is also named as Pillow Packing Machine. In the bagging and forming unit the heat sealable film such as PE/OPP, flowing horizontally flip and folds around a forming bag, then back center are imparted by vertical sealing units to seal the bag.
Model | KD-260 | KD-350 | KD-450 | KD-590 | KD-720 |
Max Film Width | 260mm | 350mm | 450mm | 590mm | 720mm |
Product Length | 40-330mm | 40-400mm | 40-450mm | 40-500mm | 40-600mm |
Product Width | 30-110mm | 40-160mm | 50-210mm | 60-280mm | 60-320mm |
Product Height | 50mm | 80mm | 80mm | 120mm | 150mm |
Intensity of Sealing | >15N/mm² | ||||
Packing Speed | 40-250 packages/minute | ||||
Packing Material | BOPP/PE, CPP/PE, CPP/PA, BOPP, CPP Anti-Fog Film, OPP Film, Color Film, and so on | ||||
Thickness of Film | 0.02-0.08mm | ||||
Power | 2.4KW 220V | 2.4KW 220V | 2.4KW 220V | 2.8KW 220V | 3.6KW 220V |
Overall Dimension | 4100x950x1500mm | 4100x1000x1500mm | 4100x1050x1500mm | 5100x1050x1700mm | 5100x1300x1700m |
Weight | 550KGS | 600KGS | 680KGS | 800KGS | 1000KGS |
Shape adjustable, easy to adjust specifications
Independent space, improve product life
Shape adjustable, easy to adjust specifications
Independent space, improve product life
Suitable for packaging of all kinds of objects with regular solid state, such as biscuits ,soap, energy bar , bread, speed wheaten food, moon cake, candy, medicines, daily necessities, etc.
Suitable for packaging of all kinds of objects with regular solid state, such as biscuits ,soap, energy bar , bread, speed wheaten food, moon cake, candy, medicines, daily necessities, etc.
