MT-200B Autoamtic Round Bottle Positioning Labeling Machine

As a fully complete automatic labeling solution, it’s designed to apply one partial or wraparound label on round containers specifically.
Equipped with ouchscreen HMI, adjustable guide rails, speed adjustable module, and conveyor, you’ll have everything you need to automate your labeling process. The adaptable structure is designed to be integrated onto existing production lines or to work as self-contained standalone units.

  • MT-200B

  • Jvan Pack

  • US$3700/Set

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
ModelMT-200B
Voltage110-220V  50/60HZ
Labeling Speed20-30 B/Min
Labeling Accuracy±1mm
Bottle Diameter 30-100mm
Applicable LabelL: 30-200mm  W: 20-150mm
Max. Label Roll Out Diameterφ260mm
Max. Label Roll Inner Diameterφ76mm
Machine Size2000*800*1400mm
Machine Weight150KG


Bottle holding type automatic labeling machine suitable for surface of the round bottle labeling, can do single label and double labels, the label position can be adjusted easily between front and back labels, widely used in cosmetics, food, medicine, disinfectant and other industries. Great improve label speed and labeling quality.

MT-200B-2


MT-200B-3

Bottle Separating Device

> Bottles on the conveying line come one by one and are labeled orderly after being separated.

Label Sensor

>Transparent label need to change the sensor.


MT-200B-4

MT-200B-5

Bottle Sensor

> High sensitivity sensor, it can detect the object when it pass by.
> Make labeling more accurate.


Bottle collecting table
> Collect bottles for easy taken.


MT-200B-6

MT-200B-7

Speed Controller

> 1. For the conveyor.
> 2. For the bottle separating device.
> 3. For the bottle roller.


MT-200B-8



MT-200B-9


company profilie

Wenzhou Jvan Machinery Co.,Ltd located in Wenzhou city, Zhejiang province, China. We have more than ten years of experience in packaging machinery, specialized in bottle filling and capping lines for food and cosmetics industry. Our product exported to more than 80 countries regions around the world and we have agent in Thailand, Greece, Slovakia and Malaysia. Good service has won strong support and trust from customers.

We absorb the advanced automation technology at domestic and abroad, develop new models, optimizethe standard technology, expand the company's scale, rely on continuous innovation, as well as rich design and production experience, with high-quality equipment and comprehensive after-sales service, has become the core enterpris of the professional packing machinery company. Our sales with apassionate and experlenced team, is always available to analyze your requirements and provide you most effective solutions and get back to you in time.
